SCANIA GRS 895 PTO PENUMATIC ISO (WITH ORGINAL TYPE ZF) (Short)
Brands:
Description
⚡ PTO – Power Take-Off ⚡
PTO or Power Take-Off is a mechanical mechanism that transfers the energy produced by the vehicle engine (such as a tractor or truck) to auxiliary equipment. This system enables various tools and devices to operate independently, eliminating the need for a separate engine.
🚜 Applications:
- Tractors: Operating agricultural equipment such as seeders, tillers, mills, and pumps.
- Trucks and industrial vehicles: Operating dumpers, hydraulic pumps, mixers, and auxiliary equipment.
⚙️ How It Works:
The PTO is typically connected to the engine or gearbox and transfers mechanical energy to the auxiliary equipment through a rotating shaft. This shaft can be a direct shaft or a hydraulic/hydromechanical connection and can operate at different speeds and rotational directions.
💡 Advantages:
- Eliminates the need for a separate engine for tools.
- Saves fuel and installation space.
- Allows the use of various equipment with a single power source.
⚠️ Safety Tips:
- Always turn off the engine before connecting or disconnecting the PTO.
- The PTO shaft rotates very fast and is dangerous; a protective cover is essential.
- Regular maintenance and proper lubrication are necessary to increase the system’s lifespan.
SCANIA GRS 905 PTO PENUMATIC ISO (WITH ORIGINAL TYPE ZF):
Used Vehicles:
SCANIA : EURO 5 – R500, R420, R440
Related Gearbox Numbers:
SCANIA : GR 875, GR 880 , GR 895, GRS 895
| Advantage | Description |
|---|---|
| Gearbox Number | GRS 895 R |
| Control Type | Pneumatic |
| Rotation |
Counter-clockwise (C.C.W, L) |
| Transmission Ratio | 1:1 |
|
shaft length |
509 mm |
📞 Technical Support and Consultation:
🛠 Raman Shams Engineering Team and PTO
The experienced engineering team of Raman Shams is ready to assist you in selecting, supplying, and reviewing the price of suitable PTO systems. Our services include the following:
- 🛠 Technical Consultation: Selecting PTOs based on your industrial needs.
- ⚙️ Installation and Setup Support: Ensuring optimal performance and longevity of the system.
- 📊 Analysis of Torque and Application Requirements: Ensuring equipment performance and durability.
- 💡 Suggested Optimized Solutions: Reducing costs and improving efficiency in the use of PTO systems.
With Raman Shams’ team, you can be confident in selecting the right PTO system for quality and price.
Additional information
| Weight | 22 kg |
|---|---|
| Torque | 436 NM |
| Power | 42.4 KW |
| Output Speed | 1250 RPM |
| Transfer rate | 1:1 |
| pump connection | ISO (4 Holes ) |
| Rotation | Left |
| Connection Type | Right Rear |
| Application | |
| Brand | |
| Warranty | Raman Shams |
| Warranty Period | Raman Shams |
| Shipped-From-Warehouse | Shiraz, Tehran |
