Ozceylanlar 4-163-1287-E Dump Truck Cylinder

Description

Telescopic Compaction Cylinders :

“Telescopic Cylinders” are a type of hydraulic actuator made up of multiple stages or hollow cylinders that extend sequentially. The arrangement of these cylinders is similar to the sections of a telescope, which allows the cylinder to extend linearly over a great distance while occupying minimal space during retraction. The nested structure typically consists of two to seven stages, where the largest cylinder or main stage houses smaller

Telescopic Cylinder for Dump Truck :

“Telescopic cylinders” are a type of hydraulic actuator composed of multiple stages or hollow cylinders that extend sequentially. The arrangement of these cylinders resembles the sections of a telescope, which allows the cylinder to occupy minimal space when retracted while providing a significant linear extension. The nested structure typically consists of six to seven stages, where the largest cylinder or main stage houses smaller cylinders inside it that extend in a controlled sequence.

Advantages of Using Telescopic Cylinder for Dump Truck :

The key advantage of telescopic cylinders lies in their ability to provide linear motion. When hydraulic fluid inside the cylinder is pressurized, it extends the stages one by one, starting from the largest section to the smallest. The design and operating model of these cylinders have two positive consequences: first, they require little space, making them usable almost anywhere; second, since these cylinders operate under hydraulic oil pressure, they generate a very high force without needing a large motor or heavy structure. As a result, they have great power to lift heavy loads.

At Raman Shams Industrial Trading Unit, various commonly used telescopic cylinders are available; moreover, any size of hydraulic telescopic cylinder requested by esteemed consumers is custom-designed and either manufactured at Raman Shams or ordered from major international companies depending on the conditions. For more information and pricing on telescopic cylinders for dump trucks, please contact us.

Ozceylanlar Single Acting Telescopic Cylinder  4-163-1287-04 :

Dump truck telescopic cylinder type E from Ozceylanlar brand in Turkey has 4 stages, with 135 mm effective diameter and approximately 130 cm closed length. This cylinder has oil volume of 40 liters, about 27 ton capacity at 190 bar and the cylinder weighs 149 kg.

Due to its high-quality construction, this type of cylinder is resistant to heavy loads and harsh conditions, making it highly applicable for use in ten-wheel trucks.

Experienced engineers at Raman Shams Industries are ready to provide consultation for the optimal selection of telescopic cylinders used in the dump trucks produced for esteemed companies and manufacturers. Additionally, you can contact the workshop unit of Raman Shams Industries to inquire about the prices of second-hand telescopic cylinders, stock antenna cylinders, and used antenna dump truck cylinders.
