Hidrotip 5-206-1675-C Dump Trailer Cylinder

🔧 Hydraulic and Pneumatic Dump Truck Cylinders:

Hydraulic and pneumatic dump truck cylinders are available in two main types. Here are the features of each:

🔧 Hydraulic Cylinders

• Performance: Utilizes hydraulic fluid to lift heavy loads.
• Features: Higher power and stability.
• Application: Suitable for heavy-duty operations requiring more power.

💨 Pneumatic Cylinders

• Performance: Operates using compressed air.
• Features: Faster operation and reduced need for electrical equipment.
• Application: Ideal for environments with minimal electrical equipment.

🔩 Hydraulic Telescopic Cylinders:

These cylinders have a special structure that makes them suitable for limited spaces and long operations.

• Structure: Made of multiple concentric tubes with varying diameters.
• Performance: Provides gradual extension, offering a longer stroke compared to standard cylinders.
• Application: Used in dump trucks, cranes, and other heavy machinery requiring compact devices.

🚚 Hydraulic Telescopic Dump Truck Cylinders:

These cylinders are used for loading and unloading operations in dump trucks and heavy equipment.

🛠 Features:

1. 🔄 Telescopic Structure: Composed of multiple stages (2-5 stages) that extend and retract telescopically.
2. In the retracted state, low height is achieved, and in the extended state, high height is achieved.
3. Used in dump trucks, trailer trucks, and excavators.
4. Suitable for unloading materials such as sand, gravel, waste, and construction materials.

💧 Hydraulic System:

• A hydraulic pump is used to operate the cylinders.
• Hydraulic pressure causes cylinder stages to open and lifts the load.

⚖ Load Capacity:

• Depending on the size and design of the cylinders, load capacity ranges from several tons to several tens of tons.

🛡 Material and Durability:

• Made from high-quality steel and coated for corrosion resistance against pressure and rust.

🔧 Installation and Maintenance:

• Specialized professionals should perform installation checking hydraulic oil levels and lubricating moving parts.

🔧 HidroTip Dump Truck Cylinders:

HidroTip is a trademark of the Turkish company Ozcelikler, established in 1975. This company is known for producing hydraulic cylinders, and its products are recognized in the market for their high quality and excellent performance.

Raman Shams Industries offers repair and after-sales services for HidroTip cylinders, including the supply of spare parts and components for hydraulic dump truck cylinders.

🚛 HidroTip Trailer Dump Truck Cylinder 5-206-1675-C :

HidroTip brand **Type C telescopic cylinder** with 5 stages, featuring the following specifications:

• First Stage Inner Diameter: 180 mm
• Retracted Length: 167 cm
• Cylinder Volume: 137 liters
• Pressure: 200 bar
• Load Capacity: Approximately 51 tons

This cylinder, due to its high-quality construction, is resistant to heavy loads and harsh conditions, making it highly practical for use in trailers.

🔧 Consultation and Services:

Experienced engineers at Raman Shams Industries are ready to offer consultation to select the best telescopic cylinders used in manufactured dump trucks for respected manufacturers.
